Abrex 500 Equivalent Plates

ABREX 500 is a high-Effectiveness wear-resistant steel plate developed by NSSMC (Nippon Steel & Sumitomo Metal Corporation). it is organized specifically for Uses where bear opposition is important devising it abstract for employ inch heavy machinery and parts open to attrition. Here's a breakdown of the important Characteristics specifications and Uses of ABREX 500:

important Characteristics:

Wear Resistance: ABREX 500 has exceptional resistance to abrasion and impact thanks to its hardness of approximately 515 BHN (Brinell Hardness Number) which is about three times that of standard mild steel.

Durability: The wear-resistant nature of ABREX 500 Adds to a very importantly longer service life for mechanical parts reducing maintenance and replacement costs.

Versatility: The material combines high hardness with excellent weldability and impact resistance making it suitable for various tough working conditions.

Specifications:

Thickness: Available in thicknesses from 5mm to 120mm.

Width: Up to 3000 mm.

Length: Up to 12000 mm.

Chemical Composition:

Carbon (C max): 0.35%

Silicon (Si max): 0.70%

Manganese (Mn max): 2.0%

Phosphorus (P max): 0.015%

Sulfur (S max): 0.010%

Nickel (Ni max): 1.00%

Chromium (Cr max): 1.20%

Molybdenum (Mo max): 0.60%

Boron (B max): 0.005%

Mechanical Properties:

Hardness: 470-530 HBW for thicknesses between 4-32 mm and 450-540 HBW for thicknesses above 32 mm.

Elongation: Minimum 10% for plates above 32 mm thickness.

Impact Toughness (Charpy V-Notch):

-40°C Impact Check: 40 J for thicknesses 4-32 mm.

For thicker plates the impact Check shows a slightly lower result (minimum 40 J for 32 mm+ thickness).

Uses:

ABREX 500 is widely used in industries requiring abrasion-resistant materials specifically for Parts subjected to heavy wear. green Uses include:

dump hand truck liners: protects the home of trucks transporting sound or rough materials

drag draw pail bear liners: old inch excavation to run the life of dragline buckets

chute liners & Check plates: protects chutes and screens inch excavation quarrying and matter Methoding

transport buckets: for conveyance materials inch industries care excavation and construction

holders & petrified scrapers: protects parts that work rough materials

benefits:

cost-Productivity: reduces care and switch costs appropriate to its increased bear resistance

extended help life: helps run the spirit of machinery and parts up to break effective Productivity

versatile inch different Uses: good for employ inch industries care excavation structure and matter treatment among others

abrex d nerve home is associate in nursing superior quality for bad developed Uses requiring great attrition opposition and strength

For more info:

Contact Us: +91-932-111-3630

 Email: mailto:[email protected]

Abrex 500 is a wear resistant plate series form NSSMC.

The usage of scratched area square ABREX 500 steel plate especially decreases the mass of extra parts seemed to serve beating conditions. Bundle and clear steel, ABREX steel plate diminishes key weight and passes on money related central concentration premiums. Request of first rate scratched an area safe ABREX 500 will surrender the assistance life of mechanical gathering and part.

ABREX 500 is through created scratched zone safe steel with a regular hardness of 515 BHN. ABREX 500 PLATES are the most wide used of the wear safe assessments. ABREX 500 plate exhibit a staggering mix of high affirmation from impact, handiness, weld cutoff and check from scratched a zone. ABREX 500 plate has around 3 times the scratched spot prospering of trustworthy steel plate and helps drawing out the association presence of mechanical parts.and ABREX 500 from 05mm ~ 50mm thickness.
