Top 5 Common Mistakes in BIM Shop Drawings and How to Avoid Them

Written by siliconvalley  »  Updated on: May 08th, 2025

BIM has revolutionized the construction industry, providing digital models that help visualize and plan every aspect of a building’s construction. However, even with BIM's advanced capabilities, mistakes can still happen when creating shop drawings, leading to costly delays, errors, and inefficiencies on the construction site. Understanding and avoiding these common mistakes can help improve the quality of BIM shop Drawings and lead to smoother project execution.


Here are the top 5 common mistakes in BIM shop drawings and how to avoid them:


1. Lack of Clash Detection

Mistake: One of the most significant advantages of BIM is its ability to detect clashes or conflicts between different building systems before construction begins. However, many BIM shop drawings fail to utilize effective clash detection, leading to on-site coordination issues, rework, and costly delays.


How to Avoid It:

Make sure that clash detection is incorporated into the BIM process from the very start. BIM tools like Autodesk Navisworks can help identify and resolve conflicts between structural, MEP, and architectural components. Always perform thorough checks and coordinate between all stakeholders (architects, engineers, and contractors) to minimize the risk of clashes. Additionally, regularly update your models to reflect any changes or new issues that arise during the project.


2. Inconsistent Detailing Across Disciplines

Mistake: BIM shop drawings typically involve multiple disciplines, including structural, architectural, and MEP (Mechanical, Electrical, Plumbing). Inconsistent detailing across these disciplines—such as discrepancies in dimensions, materials, or connections—can cause confusion during construction and result in errors on-site.


How to Avoid It:

To ensure consistency, establish clear standards and guidelines for all disciplines involved in the project. Make sure all team members are following the same practices, and that information is communicated effectively across the board. Periodic reviews and internal audits of shop drawings can help identify discrepancies early, ensuring that all team members are on the same page.


3. Incomplete or Incorrect Information

Mistake: Missing or incorrect information in BIM shop drawings—whether it’s dimensions, material specifications, or assembly instructions—can lead to construction errors and costly rework. This can also affect procurement, as manufacturers may fabricate parts based on incomplete or inaccurate data.


How to Avoid It:

Ensure that all relevant information is included in the shop drawings, including dimensions, material specifications, assembly details, and manufacturing guidelines. Double-check the accuracy of the data before finalizing the drawings, and ensure that the drawings are updated in case of design changes. Using automated tools and software to cross-check data can help minimize human error and ensure completeness.


4. Not Accounting for Real-World Conditions

Mistake: Many BIM shop drawings are based purely on idealized models without accounting for the actual conditions of the construction site. For example, site-specific challenges, such as structural variations, existing infrastructure, or environmental factors, may be overlooked in the BIM model.


How to Avoid It:

Always incorporate real-world site conditions into the BIM process. This can be achieved through the use of laser scanning, photogrammetry, or site surveys, which provide accurate, real-time data for the model. Collaborating closely with site engineers and contractors ensures that the drawings reflect the actual site conditions, preventing costly mistakes during construction.


5. Overcomplicating the Model

Mistake: While BIM allows for the creation of highly detailed models, overcomplicating the shop drawings with unnecessary details or overly intricate components can make the drawings difficult to interpret and lead to errors. Overloading the model with too much information can also slow down performance and reduce the efficiency of the team using it.


How to Avoid It:

Strike a balance between the level of detail needed and the complexity of the model. Only include the necessary information for fabrication, assembly, and construction. Keep the shop drawings as simple and clear as possible, focusing on the essential components that will affect construction. Regularly review the model and remove any unnecessary details that don’t contribute to the project's objectives.


Conclusion

BIM shop drawings are crucial for modern construction projects, offering an efficient and precise way to communicate detailed plans for fabrication and construction. However, mistakes in the process can lead to delays, errors, and added costs. By avoiding common pitfalls such as lack of clash detection, inconsistent detailing, incomplete information, ignoring real-world conditions, and overcomplicating the model, construction teams can ensure smoother project execution and higher quality outcomes.


To achieve the best results, it’s essential to invest in proper training, utilize advanced BIM tools, and maintain open communication among all team members. By doing so, you can harness the full potential of BIM shop drawings, delivering projects that are on time, on budget, and built to the highest standards of quality.
